2023 Ford Transit 148″WB High Roof AWD
$134,500 Ready Now! Less than 250 miles

Recently completed adventure camper by Pinnacle Campers ready to enable exploration beyond your wildest dreams.
We are finally starting to see a supply of vans from Ford and this one being our first 2023.
2023 Ford Transit 250 AWD, 148″WB regular length, blue metallic, ecoboost v6, swivel seats, tow/haul package, extended range fuel tank, see window sticker for all options.
Our classic Kestrel layout which includes an indoor/outdoor kitchen with hot and cold water, removable storage bins, and walnut butcher block top. Full size loft bed in the rear with slider windows and ample gear storage under. The bedside nightstand/crate tower also has removable storage crates. These are great for taking inside when loading or unloading, laundromat, grocery store, etc. weather its clothes, food, or gear, it’s super convenient. The drivers side bench seat has even more storage options and includes the portable toilet. You can set up the swiveling table at the bench seat or at the factory swivel seats. Includes a remote controlled roof fan, and opening windows for ventilation, a gasoline powered air heater, and a full set of insulated window shades.
Exterior goodies include a Flatline rack with 200watt solar panel, Van Compass Stage 1 lift kit and Method 703 wheels with Kumho RoadVenture mountain snowflake rated tires
This van weighs 7520lbs with a 9070lbs. gvw. 1550lbs capacity for occupants and gear

In stock accessories available at an extra charge:

See the full spec sheet below for details:
Upfit:
Windows: CRLaurance Driver side forward awning window, bunk slider windows
Floor Coverings: Rubber coin floor, black. Floor raised with foam insulation under
Insulation: 3M Thinsulate, roof, walls, rear and slider doors
Custom interior headliner wall panels and coverings. Automotive tweed, royal blue. Headliner, warm grey. Bench seat vinyl, Greystone
Custom Interior Cabinets: Featuring a tough waterproof epoxy coating in Light Quartz Grey
Pinnacle Campers indoor/outdoor kitchen cabinet with exterior drop down laminated table, walnut butcher block countertop, stainless sink/faucet, with pull out sprayer, setup for Dometic CFX3 45L fridge on slide out. Crate tower with 2 crates and drawer.
Nightstand crate tower on passenger side for 3 crates with , walnut butcher block countertop and shoe storage under.
Pinnacle Campers bed kit set up for east/west sleeping, Full 52×78, 4″ memory foam mattress. Wheel well storage cubbies, powerwall/integrated batteries, removable platform slat panels set at 37″ height
Bench Seat 46″, 3″ foam/vinyl upholstered seat cushions split at 50/50, storage under, porta-potty locator inside left
Large (7′) passenger side overhead cabinet with swing up door and shelf over kitchen.

Electrical: Capacities: 200ah storage, 200w solar, 30 amp engine charging, 30 amp shore/110v charging
2x 100ah Battleborn Lithium batteries
Aims Power 2000w inverter, 110v single outlet @ 4 locations
Victron BMV-712 Bluetooth battery monitor
Victron Orion DCDC Charger 12/12 30a
Victron Smartsolar MPPT 75/15
Victron 30amp shore charger with exterior Female plug and bracket
Solar panel, 200w/24volt
Exterior LED porch light over slider, LED exterior kitchen light
8 ceiling lights with dimmer, 2 zones, switched at two locations, reading lights
Cargo lighting and water pump switched at two locations
USB/DC cig plug @ 4 locations
Control panels and concealed Powerwall

Water system: 23g fresh inside, 15g grey outside, 4gal water heater
Stainless sink
Faucet, single handle, pull out spray, stainless.
Pump Shurflo 3gpm
Fresh tank 23 gallon indoor mounted, rear door fill, vented @ fill
Grey tank 10 gallon under mount (DS) with aluminum skid plate, manual dump valve, vent/over flow
Isotemp Spa water heater. Heats water using engine coolant with backup 110v element. Includes heat trace for off season use
Woder 10K water filter
Fresh water fill adapter
Rear shower quick connect port and handheld sprayer with shut off and hot/cold water valve

Appliances/Accessories:
Autoterm 4B-12v air heater with digital control, runs off on board unleaded fuel tank
Dometic CFX3 45L 12v refrigerator
DFG Off Road fridge slide
Maxxair 6200K roof fan, white lid
Lagun table leg with laminated table
Mattress: Memory foam tri fold 4”
XPLR Outfitters magnetic shades for all windows
Cab curtain/rear shower privacy kit
Duxtop 1800 watt induction cooktop
Camco portable toilet 2.6g
Hydraulic jackstand and folding lug wrench
Bug screen kit slider, Pinnacle Campers
Bug screen kit garage, Bug Wall
Ford Transit tray style floor mats

Exterior accessories:
Flatline Van Co. roof rack
Aluminess ladder/spare tire rack
Van Compass Stage 1 kit, 2″ lift with high clearance shock brackets and Falcon shocks. Installed with Alignment
Kumho Road Venture 245/75/16 5x
Method 703 Wheels 5x with TPMS for 5 tire rotation
Baja Designs Squadron Pro lights on VanCentric front light plate (not shown in pics)

Recently completed adventure camper by Pinnacle Campers ready to enable exploration beyond your wildest dreams.
We are finally starting to see a supply of vans from Ford and this one being our first 2023.
2023 Ford Transit 250 AWD, 148″WB regular length, blue metallic, ecoboost v6, swivel seats, tow/haul package, extended range fuel tank, see window sticker for all options.
Our classic Kestrel layout which includes an indoor/outdoor kitchen with hot and cold water, removable storage bins, and walnut butcher block top. Full size loft bed in the rear with slider windows and ample gear storage under. The bedside nightstand/crate tower also has removable storage crates. These are great for taking inside when loading or unloading, laundromat, grocery store, etc. weather its clothes, food, or gear, it’s super convenient. The drivers side bench has even more storage options and includes the portable toilet. You can set up the swiveling table at the bench or at the factory swivel seats. Includes a remote controlled roof fan, and opening windows for ventilation, a gasoline powered air heater, and a full set of insulated window shades.
Exterior goodies include a Flatline rack with 200watt solar panel, Baja Designs lights, Van Compass Stage 1 lift kit, and Method 703 wheels with Kumho RoadVenture mountain snowflake rated tires.
This van weighs 7520lbs with a 9070lbs. gvw. 1550lbs capacity for occupants and gear
See the full spec sheet below for details:
Upfit:
CRLaurance Driver side forward awning window, bunk slider windows
Floor Coverings, rubber coin floor, black. Floor raised with foam insulation under
Insulation, 3M Thinsulate, roof, walls, rear and slider doors
Custom interior headliner wall panels and coverings. Automotive tweed, royal blue. Headliner, warm grey. Bench seat vinyl, Greystone
Custom Interior Cabinets- Featuring a tough waterproof epoxy coating in Light Quartz Grey
Pinnacle Campers indoor/outdoor kitchen cabinet with exterior drop down laminated table, walnut butcher block countertop, stainless sink/faucet, and sprayer, setup for Dometic CFX3 45L fridge on slide out. Crate tower with 2 crates and drawer.
Nightstand crate tower on passenger side for 3 crates with , walnut butcher block countertop and shoe storage under.
Pinnacle Campers bed kit set up for east/west sleeping, Full 52×78, 4″ memory foam mattress. Wheel well storage cubbies, powerwall/integrated batteries, removable platform slat panels set at 37″ height
Bench Seat 46″, 4″ foam vinyl upholstered seat cushions split at 50/50, storage under, porta-potty locator inside left
Large (7′) passenger side overhead cabinet with swing up door over kitchen.
Electrical: Capacities: 200ah storage, 200w solar, 30 amp engine charging, 30 amp shore/110v charging, all chargers and refrigerator are accessed via bluetooth
2x 100ah Battleborn Lithium batteries
Aims Power 2000w inverter, 110v single outlet @ 4 locations
Victron BMV-712 Bluetooth battery monitor
Victron Orion DCDC Charger 12/12 30a
Victron Smartsolar MPPT 75/15
Victron 30amp shore charger with exterior Female plug
Solar panel, 200w/24volt
Exterior LED porch light over slider, LED exterior kitchen light
8 ceiling lights with dimmer, 2 zones, switched at two locations
Cargo lighting and water pump switched at two locations
USB/DC cig plug @ 4 locations
Control panels and concealed Powerwall
Water system: 21g fresh inside, 10g grey outside, 4gal water heater
Stainless sink, faucet, single handle, pull out spray, stainless.
Pump Shurflo 3gpm
Fresh tank 21 gallon indoor mounted, rear door fill, vented @ fill
Grey tank 10 gallon under mount (DS) with aluminum skid plate, manual dump valve, vent/over flow
Isotemp Spa water heater. Heats water using engine coolant with backup 110v element
Woder 10K water filter
Fresh water fill adapter
Rear shower quick connect port and handheld sprayer with shut off and hot/cold water valve
Appliances/Accessories:
Autoterm 4B-12v air heater with digital control, runs off on board unleaded fuel tank
Dometic CFX3 45L 12v refrigerator
DFG Off Road fridge slide
Maxxair 6200K roof fan, white lid
Lagun table leg with laminated table
Mattress: Memory foam tri fold 4”
XPLR Outfitters magnetic shades for all windows
Cab curtain/rear shower privacy kit
Duxtop 1800 watt induction cooktop
Camco portable toilet 2.6g
Hydraulic jackstand and folding lug wrench
Bug screen kit slider, Pinnacle Campers
Bug screen kit rear doors, Bug Wall
Ford Transit tray style floor mats
Exterior accessories:
Flatline Van Co. roof rack
Aluminess ladder/spare tire rack
Van Compass Stage 1 kit, 2″ lift with high clearance shock brackets and Falcon shocks. Installed with Alignment
Kumho Road Venture 245/75/16 5x
Method 703 Wheels 5x with TPMS for 5 tire rotation
Baja Designs Squadron Pro lights with VanCentric Front Light Plate

In stock extras available for an extra charge:
Aluminess rear passenger door bike rack with two OneUp bike trays
Trelino composting toilet Small
Baja designs LP6’s
Flatline full extension drawer
Additional 200watt solar panel
